Allen-Bradley 2711P-RP2 PanelView Plus Logic Module

Product Overview

The AB 2711P-RP2 is a robust logic module engineered for integration with Allen-Bradley PanelView Plus displays, including 700, 1000, 1250, and 1500 series. This module transforms compatible displays into complete operator terminals capable of controlling complex industrial machinery.

Designed for durability and reliability, the 2711P-RP2 operates efficiently in industrial environments between 0°C and 55°C. Its DIN rail mounting allows secure installation behind the PanelView Plus module, ensuring minimal footprint and streamlined setup.

Equipped with versatile communication interfaces, the AB 2711P-RP2 facilitates seamless connectivity through Ethernet, RS-232, and USB ports. Additionally, it includes a CompactFlash card slot for flexible data storage and transfer.

Key Features

• DC-powered logic module for PanelView Plus 700–1500 series.

• 128 MB Flash and 128 MB RAM for fast program execution and data handling.

• Multiple communication ports: Ethernet, RS-232, two USB ports.

• Compact, DIN rail-mounted design for convenient installation.

• Red and green status LEDs for immediate operational feedback.

• Power input: 24 VDC; Power dissipation: 70 W.

• Compatible with series A–G hardware; not compatible with PanelView Plus 6.

Technical Specifications

Installation Guidelines

1. Mount the AB 2711P-RP2 on the back of a compatible PanelView Plus display module.

2. Connect the 24 VDC power supply before powering the system.

3. Link required communication interfaces (Ethernet, RS-232, USB) to the control system.

4. Ensure ambient temperatures are within 0–55 °C for reliable operation.

5. Follow proper DIN rail mounting procedures and grounding standards.

FAQ

Q1: Is the AB 2711P-RP2 factory-new and original?
A1: Yes, all AB 2711P-RP2 modules are 100% original and factory-sealed.

Q2: Which PanelView Plus series are compatible with this module?
A2: Compatible with PanelView Plus 700, 1000, 1250, and 1500 series.

Q3: What memory does this logic module provide?
A3: The 2711P-RP2 offers 128 MB Flash and 128 MB RAM for efficient operations.

Q4: Which communication ports are included?
A4: The module supports Ethernet, RS-232, two USB ports, and a CompactFlash card slot.

Q5: What is the operating temperature range?
A5: Reliable operation occurs between 0°C and 55°C in industrial environments.

Q6: How long does shipping typically take?
A6: We ship within 3 days to 2 weeks, depending on order size, using DHL or similar carriers.

Q7: What is the return policy for quality issues?
A7: Returns are supported within 30 days for verified product quality concerns.
