Allen-Bradley 2711P-RSACDIN | PanelView Plus 700 DIN-Rail Power Supply Module

Overview

The 2711P-RSACDIN from Allen-Bradley is a compact DIN-rail power supply module designed for PanelView Plus 700 to 1500 operator terminals. It converts 85–265V AC input to 24V DC output, delivering up to 3 Amps of power. The module ensures reliable operation for HMI applications with stable DC voltage supply.

Its compact size of 87 × 68 × 69 mm allows easy integration into control panels. A green LED indicator signals proper output voltage above 20.4V DC, providing clear visual confirmation of normal operation. The indicator remains off if no power is applied or if the output exceeds safe limits.

Engineered for industrial environments, the 2711P-RSACDIN features robust AC-to-DC conversion with frequency support from 47 to 63 Hz. It mounts directly to standard DIN rails, ensuring simple installation while maintaining secure electrical connections.

Key Features

• Brand: Allen-Bradley / Rockwell Automation

• Model: 2711P-RSACDIN

• Series: PanelView Plus 700

• Module Type: DIN-rail AC to DC Power Supply

• Input Voltage: 85–265V AC

• Frequency: 47–63 Hz

• Output Voltage: 24V DC

• Output Current: 3 Amps

• Compatibility: PanelView Plus 700 to 1500 terminals

• Mounting: DIN rail

• Dimensions: 87 × 68 × 69 mm

• Indicator: Green LED for output voltage >20.4V DC

• Manufacturer: Rockwell Automation

Technical Specifications

Advantages

• Provides reliable 24V DC power for PanelView terminals

• Compact DIN-rail design simplifies panel installation

• LED indicator clearly shows operational status

• Wide AC input range supports industrial voltage fluctuations

• Efficient AC-to-DC conversion minimizes energy loss

• Compatible with multiple PanelView Plus terminals for flexible deployment

FAQ

Q1: Is the Allen-Bradley 2711P-RSACDIN brand new?
A1: Yes, it is fully original, factory-sealed, and brand new.

Q2: How quickly can this module be shipped?
A2: We ship within 3 days to 2 weeks depending on order size, commonly via DHL.

Q3: What is the input voltage range?
A3: The module operates on 85–265V AC, 47–63 Hz input.

Q4: What output voltage and current does the 2711P-RSACDIN provide?
A4: It delivers 24V DC at up to 3 Amps.

Q5: How is the module mounted?
A5: It mounts securely on standard DIN rails for easy integration.

Q6: Does the module have an indicator for output status?
A6: Yes, a green LED illuminates when output voltage exceeds 20.4V DC.
