Allen-Bradley 2711P-T10C4D6 PanelView Plus 1000 HMI Terminal

Product Overview

The Allen-Bradley 2711P-T10C4D6 PanelView Plus 1000 is a 10.4-inch HMI terminal designed for precise machine control in industrial automation environments. Its color touchscreen supports intuitive input, enabling operators to interact with equipment efficiently.

Equipped with dual USB ports, RS-232, and an Ethernet interface, the 2711P-T10C4D6 allows seamless integration into existing networked control systems. The terminal supports EtherNet/IP for real-time I/O messaging and application data transfers, enhancing operational flexibility.

Powered by 18–32 VDC, this PanelView terminal includes 128 MB of memory for application storage and user interface management. The internal backlight, part number 2711P-RL10C2, ensures clear visibility in various lighting conditions.

Its modular design allows connection with additional communication modules, such as the 2711P-RN20, for expanded network capabilities. The RJ45 Ethernet port supports 10/100Base-T with MDI/MDI-X auto-sensing for simplified network deployment.

Technical Specifications

Features & Advantages

• 10.4-inch color touchscreen with intuitive control interface.

• Ethernet and RS-232 ports enable flexible network integration.

• 128 MB memory supports applications and data storage.

• Internal backlight ensures readability in low-light conditions.

• USB ports allow easy data transfer and peripheral connections.

• RJ45 10/100Base-T connector supports EtherNet/IP communication.

FAQ

Q1: Is the 2711P-T10C4D6 factory-original?
A1: Yes, the 2711P-T10C4D6 is fully original and factory-new from Allen-Bradley.

Q2: What type of display does this terminal use?
A2: It features a 10.4-inch color touchscreen for direct operator input.

Q3: What communication protocols are supported?
A3: The terminal supports Ethernet, RS-232, USB, and EtherNet/IP networks.

Q4: What is the input voltage range?
A4: The 2711P-T10C4D6 operates on 18–32 VDC input.

Q5: How soon can the module be shipped?
A5: Stock is available, and shipping occurs within 3–14 days depending on order size and logistics.
