Allen-Bradley 2711P-T12W22A9P | PanelView HMI Terminal

Overview

The 2711P-T12W22A9P by Allen-Bradley is a PanelView Plus 7 performance operator terminal. It provides a human-machine interface for real-time control and communication with PLCs, PACs, and compatible devices.

Display & Touch Interface

This HMI features a 12.1-inch widescreen TFT display with 1280 × 800 WXGA resolution and 18-bit color graphics. Operator input uses an analog resistive touchscreen rated for 1 million actuations and requires 100 g of operating force.

Memory & Performance

2711P-T12W22A9P integrates 512 MB RAM and 512 MB nonvolatile memory, providing approximately 80 MB of user-available storage. It consumes a maximum of 50 W (2.1 A at 24 V DC), ensuring stable operation with minimal energy loss.

Communication & Interfaces

The terminal includes two Ethernet ports and three USB host ports. It supports multiple network topologies including linear, star, and Device Level Ring (DLR), facilitating reliable industrial communications.

Physical Specifications

This HMI weighs 5.6 pounds and measures 24.6 × 13.39 × 6.9 cm. It uses a solid-state white LED backlight with a minimum lifespan of 50,000 hours to half-brightness at 40°C. The backlight is not field-replaceable.

Applications

2711P-T12W22A9P is ideal for industrial automation systems requiring high-resolution displays and precise operator control. It ensures intuitive, real-time interaction with automation devices in demanding environments.
