Allen Bradley 2711P-T4W22D8S | PanelView Plus 7 Standard HMI

Product Overview:

The Allen Bradley 2711P-T4W22D8S is a PanelView Plus 7 Standard Human-Machine Interface (HMI) designed for industrial automation applications. This touchscreen-operated device features a wide 4.3-inch color active-matrix TFT display with a WQVGA resolution, providing clear visuals for operator control. It is built to integrate seamlessly with CompactLogix and ControlLogix controllers via Ethernet I/P communication, enhancing connectivity and operational efficiency.

Key Features:

• Model: 2711P-T4W22D8S

• Manufacturer: Allen Bradley

• Category: PanelViews

• Product Line: PanelView Plus 7

• Display Size: 4.3 inches (wide screen)

• Display Type: Color active-matrix TFT

• Display Resolution: 480 x 272 WQVGA, 18-bit color graphics

• Input Type: Touchscreen (analog resistive)

• Touch Actuation: 1 million presses with 100g operating force

• System Memory: 512 MB RAM, 512 MB non-volatile memory (approx. 80 MB free)

• Communication Ports: 2 Ethernet, 2 USB

• Input Voltage: 18-30 VDC

• Power Consumption: 35W max (1.46A at 24VDC)

• Backlight Life: 50,000 hours min at 40°C to half-brightness (non-replaceable)

Technical Specifications:

Product Description:

The Allen Bradley 2711P-T4W22D8S is an advanced PanelView Plus 7 Standard terminal, designed to provide superior control and monitoring capabilities in industrial settings. This HMI device integrates a 4.3-inch wide color TFT display with WQVGA resolution, delivering high-quality visuals for easy operator interaction.

Its touchscreen interface features analog resistive technology, offering a precise and durable user experience with 1 million press actuations. The system memory of 512MB RAM and 512MB non-volatile memory ensures fast and reliable performance, with approximately 80MB of free user memory.

Equipped with two Ethernet and two USB ports, this terminal facilitates seamless communication with CompactLogix and ControlLogix controllers, supporting Ethernet I/P communication for high-speed data exchange. The input voltage range of 18-30 VDC ensures compatibility with various industrial power systems, while the 35W power consumption ensures energy efficiency.

Built for long-term operation, the 2711P-T4W22D8S features a backlight life of 50,000 hours, offering excellent performance in diverse industrial environments. This HMI terminal is ideal for applications where ease of use, reliable performance, and efficient communication are paramount.

FAQ:

Q1: What is the display size of the 2711P-T4W22D8S?
A1: The 2711P-T4W22D8S has a 4.3-inch wide display.

Q2: What type of communication ports does the 2711P-T4W22D8S support?
A2: The 2711P-T4W22D8S features two Ethernet ports and two USB ports for seamless connectivity.

Q3: What is the resolution of the display on the 2711P-T4W22D8S?
A3: The display offers 480 x 272 WQVGA resolution with 18-bit color graphics.

Q4: How much memory does the 2711P-T4W22D8S HMI have?
A4: The 2711P-T4W22D8S is equipped with 512MB RAM and 512MB non-volatile memory, with approximately 80MB of free user memory.

Q5: What is the backlight life of the 2711P-T4W22D8S?
A5: The backlight of the 2711P-T4W22D8S has a 50,000-hour minimum life at 40°C to half-brightness.
