Allen-Bradley 2711P-T7C21D8S PanelView Plus 7 Operator Terminal

Overview

The Allen-Bradley 2711P-T7C21D8S is a PanelView Plus 7 operator terminal designed for industrial automation applications. It features a 6.5-inch widescreen colored display with an embedded touchscreen interface, powered by an external 18–30 VDC supply. The terminal provides one Ethernet port and two USB ports for seamless communication.

Technical Specifications

• Display Size: 132 x 99 mm

• Display Type: 6.5 inches, widescreen, TFT color display

• Resolution: 640 x 480 VGA, 18-bit color graphics

• Touchscreen: Analog resistive, actuable up to 1 million presses, operating force 100 g

• Application Memory: 512 MB RAM, 512 MB storage, 80 MB user memory

• Communication Ports: 1 Ethernet, 2 USB, 1 RS-232

• Input Voltage Range: 18–30 VDC (nominal 24 VDC)

• Backlight: CCFL, 50,000-hour minimum life

• Input Type: Touchscreen

• Weight: 2.65 lbs

• Product Family: PanelView Plus 7

• Part Number/Catalog No.: 2711P-T7C21D8S

• UPC: 885630920504

Features and Benefits

• Operator Interaction: Analog resistive touchscreen allows direct control, navigation, and data modification.

• Durability: Capable of 1 million actuations with minimal force (100 g).

• Memory Expansion: Supports SD cards and USB flash drives for additional storage.

• Real-Time Clock: Battery-backed RTC with ±2 minutes/month accuracy, lifespan of 4 years at 25 °C.

• Power Efficiency: Max power consumption of 50 W.

• Flexible Installation: Flush-mountable panel cut-out: 142 x 184 mm (5.59 x 7.24 in.), compatible with NEMA/UL Type 12, 13, 4X enclosures, IP54/IP66 rated.

This Allen-Bradley 2711P-T7C21D8S operator terminal provides a robust and user-friendly solution for advanced human-machine interface (HMI) applications, combining high-resolution graphics, responsive touchscreen input, and versatile connectivity for modern industrial systems.
