Allen-Bradley 2711P-T7C22A9P | PanelView Plus 7 Performance HMI

Product Overview

The 2711P-T7C22A9P from Allen-Bradley is a PanelView Plus 7 Performance operator terminal designed for advanced visualization and control. It integrates PLC and PAC data while providing operators with an intuitive analog resistive touchscreen rated for one million actuations.

Display and Interface

The 2711P-T7C22A9P is equipped with a 6.5-inch color TFT display, delivering 640 x 480 VGA resolution and 18-bit graphics for sharp and clear visualization. Its active display area measures 304 x 228 mm, ensuring enough space for complex process graphics and interactive layouts.

Memory and Performance

This HMI provides 1GB of system RAM and 512 MB of nonvolatile storage, offering approximately 80 MB of user-available memory. These resources support larger applications, custom graphics, and extensive data handling capabilities in demanding industrial environments.

Connectivity Options

The 2711P-T7C22A9P supports dual Ethernet ports and three USB host connections, enabling efficient communication with controllers, networks, and external devices. These ports allow fast data exchange and smooth integration with modern automation systems.

Power and Durability

The device operates with an input voltage range of 100–240VAC and consumes 105 VA of power. A solid-state LED backlight provides a minimum of 50,000 hours of service life at 40 °C, although it is non-replaceable. Weighing 2.65 lbs, the 2711P-T7C22A9P combines durability and compactness for reliable use in industrial environments.
