Allen-Bradley 2711PC-T6C20D8 | PanelView Plus 6 Compact HMI

Product Overview

The 2711PC-T6C20D8 is an Allen-Bradley PanelView Plus 6 Compact 600 operator terminal, providing a graphical interface for industrial monitoring and control. Its 5.7-inch TFT color display supports 320 x 240 resolution and 18-bit color graphics for accurate data visualization.

Display and Input Features

This terminal integrates an analog resistive touchscreen for intuitive operator input. Users can interact directly with machine data, ensuring fast response times and reliable operation.

Memory and Processing

The 2711PC-T6C20D8 includes 256 MB RAM and 512 MB nonvolatile memory, with roughly 79 MB available for user applications. It stores up to 200 alarm messages and supports up to 25 display screens.

Communication and Connectivity

The 2711PC-T6C20D8 supports Ethernet, RS-232, and two USB host ports for flexible communication and peripheral connectivity. It enables remote connectivity, ActiveX control, and easy integration into industrial networks.

Power and Environmental Specifications

Powered by 18–32V DC, this compact terminal consumes low power and supports NEMA/UL Type 12, 13, 4X enclosures, along with IEC IP66 rating for indoor use. Its white LED backlight lasts a minimum of 25,000 hours at 25 °C.

Physical Dimensions and Mounting

The 2711PC-T6C20D8 measures 6 x 7.28 x 2.86 inches, weighs 1.31 pounds, and is optimized for panel mounting. Its compact design supports industrial installations with limited space.

Additional Features

This terminal provides built-in PDF viewing, vector-based graphics, CSV file handling, and automated data backup for reliability. Users can manage and modify data efficiently with a login-enabled interface.
