Allen Bradley 2713P-T7WD1 | PanelView 5310 Operator Interface

Product Overview

The Allen Bradley 2713P-T7WD1 is a PanelView 5310 operator interface designed for ControlLogix 5570, 5580, and CompactLogix L1-L3 systems. It features a 7-inch widescreen TFT color display with 800x480 WVGA resolution and a 5:3 aspect ratio for clear, detailed visualization.

Its analog resistive touchscreen supports over one million presses with a 100-gram actuation force, enabling precise operator input. The terminal includes 1 GB RAM and 500 MB non-volatile storage, expandable via SD card (1784-SDx), for efficient application management.

The 2713P-T7WD1 supports Ethernet communication and two high-speed USB ports, allowing flexible integration and data exchange. Its rugged design accommodates industrial environments with an operating temperature of 32–122°F and non-condensing humidity range of 5–95%.

Powered by 18–30 VDC, this terminal consumes a maximum of 13 W and dissipates 31 BTU/hr. Its compact footprint and 6-lb weight allow easy installation in control panels.

Key Features

• 7-inch TFT color display with 800x480 WVGA resolution and 5:3 aspect ratio.

• Analog resistive touchscreen rated for 1 million presses, 100 g actuation force.

• 1 GB RAM and 500 MB non-volatile storage; SD card slot for expansion.

• Communication ports: 1 Ethernet, 1 Type A USB host, 1 Type B USB device.

• Red/green status indicator for operational feedback.

• Operating temperature: 32–122°F; storage: -13–158°F; humidity: 5–95%.

• Input voltage: 18–30 VDC, nominal 24 VDC; typical power: 9 W, max: 13 W.

• Backlight life: 50,000 hours half-life; power dissipation: 31 BTU/hr.

Technical Specifications

Industrial Applications

The Allen Bradley 2713P-T7WD1 is ideal for visualization and operator input in industrial automation. It works with ControlLogix and CompactLogix systems, providing operators clear control of processes. Its touchscreen and multiple communication ports allow integration with HMIs, PLCs, and other control devices.

FAQ

Q1: Is the Allen Bradley 2713P-T7WD1 brand new and original?
Yes, we supply brand new original Allen Bradley PanelView 5310 terminals.

Q2: Do you have the 2713P-T7WD1 in stock?
Yes, inventory is available and usually ships within 3 days to 2 weeks depending on order size.

Q3: Which shipping options are supported?
We ship via DHL, FedEx, UPS, or customer-specified carriers.

Q4: What if there is a quality issue with the terminal?
We support returns within 30 days for any quality-related problems.

Q5: Can the 2713P-T7WD1 storage be expanded?
Yes, via the 1784-SDx SD card slot.

Q6: What environments can this terminal operate in?
It works reliably in 32–122°F with 5–95% non-condensing humidity.
