Allen-Bradley 5069-L340ERM | CompactLogix Ethernet Motion Controller
Specifications
Manufacturer: Allen Bradley
Product No.: 5069-L340ERM
Condition： 10 Items in Stock
Product Type: Motion Controller
Product Origin: USA
Payment:T/T, Western Union
Weight: 750g
Shipping port: Xiamen
Warranty: 12 months
Product details
Description
Overview
The Allen-Bradley 1769-IF4XOF2 is a compact I/O module designed for CompactLogix and MicroLogix 1500 controllers. This versatile module integrates 4 analog input channels and 2 analog output channels, providing a cost-effective solution for general process control tasks. It is ideal for applications where high-resolution accuracy is not critical but reliable performance is required.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Inputs | 4 analog input channels |
| Input Type | Voltage (0 to 10.5 VDC), Current (0 to 21 mA) |
| Input Voltage Range | 0 to 10.5 VDC |
| Input Current Range | 0 to 21 mA |
| Resolution | 8 bits plus sign (always positive) |
| Impedance (Voltage Terminal) | 150 kΩ |
| Impedance (Current Terminal) | 150 Ω |
| Accuracy (Voltage Input) | ±0.7% |
| Accuracy (Current Input) | ±0.6% |
| Outputs | 2 single-ended analog outputs |
| Output Voltage Range | 0 to 10 VDC |
| Output Current Range | 0 to 20 mA |
| Output Accuracy | ±0.5% full scale |
| Load Specifications (Voltage) | Min load > 1 kΩ at 10 VDC |
| Load Specifications (Current) | Max load of 300 ohms |
| Response Time (Current Output) | 0.3 ms (resistance), 3.0 ms (capacitance) |
| Operational Voltage | 30 VDC/AC |
| Common Mode Voltage | 10 VDC per channel |
| Signal Type | Differential or Single-ended |
| Converter Type | Delta Sigma converter |
| Power Supply Distance Rating | Max 8 modules from the power supply in CompactLogix systems |
| Enclosure | Open-style, DIN rail or panel mountable |
Product Description
The Allen-Bradley 1769-IF4XOF2 combines analog inputs and outputs in a single, compact unit, offering significant flexibility for process control and automation applications. It supports voltage and current signals, with configurable inputs for differential or single-ended connections. With an operational voltage of 30 VDC/AC, this module is ideal for integration into systems where space is limited but performance is key.
Mounting and Compatibility
This module is designed to be mounted on DIN rail and is fully compatible with CompactLogix and MicroLogix 1500 controllers. The 1769-IF4XOF2 features over-range detection and process alarms to ensure optimal performance during operations. For easy wiring, it supports differential and single-ended signal types.
Advantages
-
Dual functionality with 4 analog inputs and 2 analog outputs in one compact module.
-
Flexible input types for voltage and current signals, supporting a wide range of applications.
-
Compact design for easy installation and integration in space-constrained systems.
-
High response accuracy, especially for current output with a rapid response time of 0.3 ms.
FAQ
Q: What is the input voltage range for the 1769-IF4XOF2 module?
A: The 1769-IF4XOF2 supports an input voltage range of 0 to 10.5 VDC.
Q: How many input channels are available on this module?
A: The 1769-IF4XOF2 offers 4 analog input channels.
Q: Can this module handle both voltage and current signals?
A: Yes, it supports voltage (0 to 10.5 VDC) and current (0 to 21 mA) signals.
Q: What is the accuracy of the current input on this module?
A: The current input accuracy is ±0.6%.
Q: How is this module mounted?
A: The 1769-IF4XOF2 is designed for DIN rail mounting, allowing for easy installation.
Q: How long does shipping take?
A: Shipping usually takes between 3 days to 2 weeks, depending on order size and location.
Q: Is the module original and brand new?
A: Yes, the 1769-IF4XOF2 is brand new and original with a 12-month warranty.
