Allen-Bradley 5069-OB16F | Compact DC Output Module

Product Overview

The Allen-Bradley 5069-OB16F Compact DC Output Module is engineered for high-speed switching applications that demand precision and durability. With a maximum switching frequency of 5000 Hz and a 1ms response time, it delivers exceptional performance in time-critical industrial processes.

This module supports both Modbus TCP/IP and DeviceNet communication protocols, ensuring seamless integration into existing control architectures. Its compact 100 x 50 x 30 mm design, paired with robust materials, makes it easy to install in space-limited control cabinets while maintaining industrial-grade reliability.

Technical Specifications for 5069-OB16F

Features and Benefits

• 5069-OB16F offers 16A high-capacity output with 30V DC rating for stable control.

• Fast 1ms response time and 5000 Hz switching frequency suit time-critical applications.

• Dual protocol support (Modbus TCP/IP and DeviceNet) enhances flexibility and connectivity.

• Compact and lightweight design enables efficient installation in tight control panels.

• Wide operating temperature range ensures reliability in diverse industrial conditions.

Applications

The Allen-Bradley 5069-OB16F is widely applied in manufacturing, packaging, material handling, and energy management systems. Its high-speed switching capability and strong environmental tolerance make it ideal for robotics, conveyor systems, and motion control tasks.

FAQ

Q1: What is the maximum output current of the 5069-OB16F?
It delivers up to 16A across its output channels.

Q2: How fast is the switching response time?
The module operates with a rapid 1ms response time for precise control.

Q3: What communication protocols does it support?
The 5069-OB16F supports Modbus TCP/IP and DeviceNet protocols.

Q4: What is the recommended operating temperature range?
It functions reliably between -20°C and +70°C.

Q5: Is the 5069-OB16F module protected against dust or contact?
Yes, it is rated IP20, providing protection against solid object intrusion.

Q6: Do you supply brand-new units in stock?
Yes, we provide new original Allen-Bradley 5069-OB16F modules, shipping within 3 days to 2 weeks depending on order size.

Q7: What if I encounter a quality issue?
We support returns within 30 days for any verified quality problems.

Q8: Which shipping couriers are available?
We typically ship via DHL, FedEx, or UPS to ensure fast and reliable delivery.
