Allen-Bradley Industries 1786-RG6F High-Flex Coaxial Cable

Product Overview

The AB 1786-RG6F is a high-performance coaxial cable engineered for industrial environments demanding flexibility and reliable signal transmission. It features Teflon (PTFE) insulation and a braided shield to ensure excellent conductivity and protection against harsh conditions.

With a UL-listed grade 6 flexibility rating, the 1786-RG6F withstands continuous flex applications and up to 1000 bending cycles without degradation. Its insulation resistance exceeds 10^10 ohms, preventing short circuits and supporting safe, reliable operation.

Designed for broad environmental compatibility, the cable operates from -40°C to +85°C and supports frequencies from DC to 1 GHz. The solid 22 AWG copper conductor enables stable signal transmission, while its modular design facilitates integration into existing systems.

Weatherproof connectors and various wire size options (AWG #22 to #10) ensure secure connections and adaptability in both indoor and outdoor applications.

Key Features

• Material: PTFE-insulated, braided shield for durability and performance.

• Flexibility: UL-listed for continuous flex applications, grade 6 rating.

• Conductor: 22 AWG solid copper for reliable signal transmission.

• Operating Frequency: DC to 1 GHz for high-fidelity data transfer.

• Temperature Range: -40°C to +85°C for extreme industrial conditions.

• Insulation Resistance: >10^10 ohms to prevent short circuits.

• Voltage Rating: 0–100 V DC compatible with various power sources.

• Modular Design: Supports diverse wire sizes and easy system integration.

Technical Specifications

Applications

• Industrial automation and control systems

• Harsh environment data transmission

• Factory and process monitoring networks

• Outdoor or flexible installation requirements

FAQ

Q1: Is the AB 1786-RG6F coaxial cable brand new?
A1: Yes, all AB 1786-RG6F cables are original factory-new units.

Q2: What is the maximum operating frequency?
A2: It supports DC to 1 GHz signal transmission for high-fidelity data.

Q3: Can it handle continuous flex applications?
A3: Yes, it has a UL-listed grade 6 rating and withstands up to 1000 bending cycles.

Q4: What is the temperature tolerance?
A4: The cable operates reliably between -40°C and +85°C.

Q5: What connector options are available?
A5: It comes with weatherproof connectors suitable for both indoor and outdoor installations.

Q6: How fast is shipping?
A6: Orders ship within 3 days to 2 weeks depending on quantity, via DHL or similar couriers.

Q7: Is there a return policy?
A7: Returns are supported within 30 days for verified quality issues.
