Allen-Bradley MVI56E-GSC | Generic ASCII Serial Enhanced Communication Module

Product Overview

The MVI56E-GSC from Allen-Bradley is a Generic ASCII Serial Enhanced Communication Module designed for ControlLogix platforms. It allows PACs to interface efficiently with non-specific ASCII serial devices, supporting byte-based communication protocols.

This module features 1 slot with local or remote rack configuration, enabling flexible installation options in a variety of industrial setups. Users benefit from ladder logic data transfer, simplifying integration with automation systems.

Equipped with two fully configurable serial ports, the MVI56E-GSC conserves valuable processor front port bandwidth, improving overall system efficiency. Its Ethernet configuration (10/100 Mbps) supports remote diagnostics and local monitoring, enhancing operational reliability.

Additionally, this Allen-Bradley module incorporates CIPconnect technology for optimized ControlNet and Ethernet/IP network integration. The onboard web server provides status information, sample programs, and documentation to support fast deployment.

Built to withstand harsh environments, the MVI56E-GSC has a 30g operational shock rating and a backplane current load of 800 mA @ 5V DC, ensuring stable performance in industrial conditions.

Technical Specifications

Key Features

• Dual Configurable Serial Ports: Enhances communication without using processor front ports.

• Flexible Rack Installation: Supports local or remote rack configurations.

• Ethernet Enabled: 10/100 Mbps for remote monitoring and diagnostics.

• Ladder Logic Data Transfer: Simplifies integration with ControlLogix systems.

• Rugged Construction: 30g operational shock rating ensures reliability.

Applications

• Industrial automation and ControlLogix integration

• Non-specific ASCII serial device communication

• Remote and local diagnostics for serial networks

• Efficient PAC-to-device serial data transfer

FAQ

Q1: Is the MVI56E-GSC module in stock?
Yes, we offer new, original Allen-Bradley MVI56E-GSC modules ready for shipping within 3–14 days depending on order size.

Q2: How many serial ports does it support?
The module supports two fully configurable serial ports for versatile communication.

Q3: What is the supported baud rate range?
It operates from 110 baud to 115.2 kbps for various serial devices.

Q4: Can this module be mounted in a remote rack?
Yes, the MVI56E-GSC supports local or remote rack installation.

Q5: Does it support Ethernet diagnostics?
Yes, the module features 10/100 Mbps Ethernet for remote diagnostics and local monitoring.
