DATAFORTH SCMPB01 Signal Conditioning Backplane

Description

The DATAFORTH SCMPB01 is a 16-channel signal conditioning backplane designed for use with SCM5B analog modules. It provides a dedicated analog bus per module and supports high-speed data acquisition systems.

Specifications

• Model Number: SCMPB01

• Manufacturer: DATAFORTH Corporation

• Channel Capacity: 16 non-addressable analog I/O channels

• Module Compatibility: Accepts any SCM5B analog module

• Mounting: Fits SCMXRK-002 19-inch metal rack

• Output Access: All 16 module outputs are simultaneously accessible

• Power Supply: Supplied via system backplane

• Inter-Channel Connectivity: Bridge jumpers allow input-to-output module linking

• Temperature Monitoring: Integrated sensor on each channel

• Signal Routing: Non-multiplexed analog bus per module

• Dimensions: Standard rack-mountable form factor

• Application: High-speed ADC systems, industrial signal conditioning

Features

• Dedicated Analog Bus: Each module has its own continuous output path

• Simultaneous Access: All outputs available for real-time data acquisition

• Modular Flexibility: Supports mixed SCM5B module configurations

• Bridge Jumpers: Enable two-level isolation between input and output modules

• Rack Compatibility: Mounts directly into standard 19-inch SCMXRK-002 rack

• Thermal Monitoring: Channel-level temperature sensors enhance diagnostics

• Industrial Reliability: Designed for rugged environments and long-term operation

• Non-Multiplexed Design: Ensures low-latency signal flow for precision systems
