DELL POWERCONNECT 2824 Gigabit 24 Port Network Switch

Description

The DELL PowerConnect 2824 is a 24-port Gigabit Ethernet switch designed for small to medium-sized networks. It offers high-speed connectivity, flexible management options, and reliable performance for business-critical applications.

Specifications

• Model Number: PowerConnect 2824

• Manufacturer: Dell Inc.

• Switch Type: Layer 2 Gigabit Ethernet switch

• Port Count: 24 × 10/100/1000BASE-T ports + 2 × SFP combo ports

• Switching Capacity: 48 Gbps

• Forwarding Rate: 35.6 Mpps

• MAC Address Table: 8,000 entries

• Buffer Memory: 256 KB

• Transmission Mode: Full/half duplex auto-negotiation

• Management Options: Web GUI, CLI, SNMP, RMON

• VLAN Support: Up to 64 port-based VLANs

• QoS: 4 priority queues per port, supports 802.1p and DSCP

• Power Supply: Internal, 100V AC, 1A

• Dimensions: 42 × 330 × 230.5 mm

• Operating Temperature: 0°C to 45°C

Features

• High-Speed Connectivity: Delivers full line-rate switching across all ports

• Flexible Deployment: Supports desktop and rack-mount installations

• Web-Managed Mode: Easily configurable via front-panel button

• Advanced Traffic Control: Includes QoS, VLAN, and port mirroring features

• Energy Efficient: Fanless design reduces power consumption and noise

• Link Aggregation: Supports static trunking and 802.3ad for bandwidth scaling

• Broadcast Storm Control: Prevents network congestion and packet loss

• Jumbo Frame Support: Handles packets up to 9000 bytes for large data transfers

• Lifetime Warranty: Dell provides limited lifetime hardware coverage
