DS200IMCPG1CGC - IGBT Power Supply Board in Stock

SPECIFICATIONS

• Part Number: DS200IMCPG1CGC

• Manufacturer: General Electric

• Series: Drive Control

• Product Type: IGBT Power Supply Board

• Operating Temperature: 0 to 60°C (32 to 149°F)

• Availability: In Stock

• Country of Manufacture: United States (USA)

Functional Description

The DS200IMCPG1CGC is an IGBT Power Supply Board developed by General Electric as part of their drive control system. It plays a crucial role in controlling and regulating power distribution within the panel, thereby contributing to the efficient and reliable operation of various systems and subsystems.

This board integrates advanced control mechanisms and protective features, including but not limited to overcurrent protection, overvoltage protection, thermal management, and fault detection, to ensure the overall safety and stability of the system.

Features

• Comprehensive Diagnostics: Power requirements are carefully managed via a diagnostic system that monitors the health and stability of each voltage source and feeder, including the fuses within each solenoid circuit on the relay terminal board.

• Flexible Power Integration: The Mark V panel supports seamless integration of power from multiple sources, providing both flexibility and redundancy. Each power input source—whether DC or AC—must pass through its own external 30 A, 2-pole thermal magnetic circuit breaker before entering the panel, ensuring protection and isolation.

• Versatile Power Sources: The panel can operate from a combination of up to two 120/240 V AC sources and/or one 125 V DC source, allowing adaptable configurations for diverse operational requirements.

• Centralized Power Distribution: Each core inside the panel has its own power supply board; however, all boards are connected via a common 125 V DC panel distribution bus. This centralized system guarantees consistent and reliable power delivery throughout the panel, optimizing performance and operational reliability.

Note: WOC maintains the largest stock of Speedtronic control spares. For pricing and availability of parts and repairs, please contact our staff via phone or email.
