DS200LDCCH1ANA | GE | LAN Communications Board

Description

DS200LDCCH1ANA is a GE LAN Communications Board for Drive Control systems, enabling precise motor control and reliable LAN communication.

Configuration Storage

• Configuration data stored in six flash PROMs (U7-U21) on the base circuit.

• Fast and reliable access to configuration data.

Noise Immunity

• Additional stab connector reduces electrical interference.

• Ensures stable and accurate signal transmission in high-noise environments.

Signal Conversion

• Supports analog-to-digital (A/D) and digital-to-analog (D/A) conversions.

• Maintains integrity and precision of control signals between components.

Input Interface

• Supports voltage-controlled oscillator (VCO) inputs.

• Enables precise control over frequency and voltage parameters.

Data Handling

• Built-in I/O peripherals.

• Direct Memory Access (DMA) controller for high-speed data transfer.

• Reduces CPU load by offloading data communication tasks.

User Interface

• 16-character digital display for real-time status and diagnostics.

• KPPL connector for easy connection to other components or diagnostic tools.
