Emerson Epro CON021/PR6423/010-010 Epro Eddy Current Sensor

Description

The Emerson Epro CON021/PR6423/010-010 sensor system integrates a PR6423 probe with a CON021 converter, delivering accurate shaft vibration and position measurements for industrial turbomachinery applications.

Specifications

• Brand/Manufacturer: Emerson

• Country of Origin: USA

• Model: CON021/PR6423/010-010

• Type: Eddy current sensor system

• Sensor Diameter: 8 mm

• Measurement Range: 2 mm (80 mils)

• Initial Gap Setting: 0.5 mm (20 mils)

• Sensitivity: 8 V/mm (203.2 mV/mil) ±5%

• Target Material: Ferromagnetic steel (e.g., 42CrMo4)

• Minimum Shaft Diameter: 25 mm

• Protection Class: IP66

• Operating Temperature: Sensor: -35°C to +180°C; Cable: up to +150°C

• Dimensions: 24 cm × 17 cm × 6 cm

• Weight: 0.66 kg

Features

• Non-Contact Monitoring: Enables precise shaft vibration and displacement measurement without physical contact

• High Sensitivity: Delivers accurate readings across wide temperature and frequency ranges

• Modular Configuration: Combines probe and converter for flexible installation and maintenance

• Industrial Durability: Built to withstand harsh environments and mechanical stress

• Real-Time Diagnostics: Supports predictive maintenance and early fault detection

• Wide Compatibility: Suitable for turbines, compressors, pumps, and other rotating equipment

• Reliable Performance: Proven technology for continuous operation in critical applications
