Emerson EZ1080-05-00-010 Eddy Current Displacement Sensor – 8 mm
Specifications
Manufacturer: Emerson
Product No.: EZ1080-05-00-010
Condition： 10 Items in Stock
Product Type: Eddy Current Displacement Sensor
Product Origin: USA
Payment:T/T, Western Union
Weight: 100g
Shipping port: Xiamen
Warranty: 12 months
Product details
Description
Emerson EZ1080-05-00-010 Eddy Current Displacement Sensor
Product Overview
The Emerson EZ1080-05-00-010 is a high-precision eddy current displacement sensor designed for non-contact vibration and shaft monitoring in rotating machinery. With a standard M10 × 1 mount and a 50 mm stainless steel body, it provides durability and accuracy for use in turbines, compressors, pumps, and other heavy-duty industrial equipment. Its 8 mm sensing diameter and linear measurement range of 2 mm make it suitable for tight tolerances and critical reliability applications.
Engineered for demanding environments, the EZ1080-05-00-010 features robust stainless steel housing, glass-fiber reinforced sensor tip, and IP67 protection rating, ensuring stable operation under extreme conditions.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | EZ1080-05-00-010 |
| Manufacturer | Emerson |
| Product Type | Eddy Current Displacement Sensor |
| Sensor Diameter | 8 mm |
| Mounting Configuration | Standard mount |
| Thread Size | M10 × 1 |
| Body Length | 50 mm |
| Cable Length | 1.0 meter (non-armored) |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | API: 7.87 V/mm ±5%; ISO: 8 V/mm ±5% |
| Straightness Deviation (DSL) | ±0.02 mm |
| Minimum Target Size | 14 mm (recommended ≥20 mm) |
| Minimum Shaft Diameter | 20 mm (recommended ≥25 mm) |
| Target Material Compatibility | Ferromagnetic steels (42CrMo4, C35, S235JR) |
| Operating Temperature (Sensor) | –35°C to +180°C |
| Operating Temperature (Cable) | –35°C to +150°C |
| Protection Rating | IP67 standard (IP68 optional) |
| Rated Pressure | 10,000 hPa (145 psi) |
| Material Composition | Tip: Glass-fiber reinforced PEEK; Case: Stainless steel; Cable: FEP |
| Dimensions | 5.5 in × 2.5 in × 1.5 in |
| Weight | 0.1 kg (100 g including cable) |
| Country of Origin | USA |
| Condition | New & In Stock |
| Unit Price | USD165 |
| Payment Methods | T/T, Western Union |
