Emerson EZ1080-08-00-010 Eddy Current Displacement Sensor – AMS EZ1000
Specifications
Manufacturer: Emerson
Product No.: EZ1080-08-00-010
Condition： 10 Items in Stock
Product Type: Eddy Current Displacement Sensor
Product Origin: USA
Payment:T/T, Western Union
Weight: 100g
Shipping port: Xiamen
Warranty: 12 months
Product details
Description
Emerson EZ1080-08-00-010 Eddy Current Displacement Sensor
Product Overview
The Emerson EZ1080-08-00-010 is a precision-engineered eddy current displacement sensor designed for accurate shaft vibration, displacement, and position measurement in rotating machinery. As part of the AMS EZ1000 series, this sensor ensures high reliability, modular flexibility, and excellent performance in harsh industrial conditions such as turbines, compressors, and pumps.
It features a robust 8 mm sensing tip, M10 × 1 threaded standard mount, and a 1-meter non-armored cable, making it suitable for compact installations while maintaining exceptional measurement accuracy.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | EZ1080-08-00-010 |
| Manufacturer | Emerson |
| Product Type | Eddy Current Displacement Sensor |
| Sensor Series | AMS EZ1000 |
| Tip Diameter | 8 mm |
| Mounting Type | Standard (code 08) |
| Thread Size | M10 × 1 |
| Unthreaded Length | None (code 00) |
| Cable Type | Non-armored |
| Cable Length | 1.0 meter |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | API: 7.87 V/mm ±5%; ISO: 8 V/mm ±5% |
| Linearity Deviation (DSL) | ±0.025 mm (±1 mil) |
| Minimum Target Size | 14 mm (recommended ≥20 mm) |
| Minimum Shaft Diameter | 20 mm (recommended ≥25 mm) |
| Target Material | Ferromagnetic steels (e.g., 42CrMo4, C35, S235JR) |
| Operating Temperature (Sensor) | –35 °C to +180 °C |
| Operating Temperature (Cable) | –35 °C to +150 °C |
| High-Temperature Capability | Sensor tip withstands up to +260 °C (optional) |
| Protection Class | IP67 standard; IP68 optional with certification |
| Pressure Resistance | 10,000 hPa (145 psi) at 120 °C |
| Sensor Tip Material | Glass-fiber reinforced PEEK |
| Cable Material | FEP (Fluorinated Ethylene Propylene) |
| Connector Material | Nickel-plated brass |
| Dimensions | 5.5 in × 2.5 in × 1.5 in |
| Weight | 100 g |
