EMERSON KJ4005X1-BA1 POWER/CONTROLLER CARRIER

Description

The EMERSON KJ4005X1-BA1 is a system carrier module used in DeltaV S-series distributed control systems. It provides structured power delivery and controller support for efficient system integration.

Specifications

• Manufacturer: Emerson

• Country of Origin: USA

• Model: KJ4005X1-BA1

• Type: Power/controller carrier

• Local Bus Power: 12 VDC at 15 A

• Field Power Capacity: 30 VDC at 3 A per card (8-wide carrier)

• Operating Temperature: -40°C to +70°C

• Shock Resistance: 10 g, ½ sinewave for 11 ms

• Vibration Resistance: 1 mm peak-to-peak (2–13.2 Hz), 0.7 g (13.2–150 Hz)

• Humidity Range: 5% to 95% non-condensing

• Airborne Contaminants: ISA-S71.04 Class G3

• Mounting: DIN rail or rack installation

• Dimensions: 200 × 100 × 50 mm

• Weight: Approx. 1.5 kg

Features

• Controller Support: Provides mechanical and electrical support for DeltaV controllers

• Power Distribution: Delivers regulated power to I/O modules and field devices

• Modular Design: Enables flexible system expansion and configuration

• Industrial Durability: Built to withstand harsh environmental conditions

• Easy Installation: Simplified mounting and wiring for quick deployment

• System Integration: Seamlessly fits into DeltaV architecture for centralized control

• Redundancy Ready: Supports redundant power configurations for high availability
