FS-TPSU-2430 Honeywell DC/DC Converter

The Honeywell FS-TPSU-2430 is a compact DC/DC converter designed for industrial power regulation applications. It converts a nominal 24 VDC input supply into a regulated 24-30 VDC output at up to 1 A, providing power for sensors, actuators, and electronic control circuits.

Power Conversion and Efficiency

The converter operates with an efficiency rating of 80%, converting 24 VDC input power into a steady 24-30 VDC output. With a maximum output current capacity of 1 A, it satisfies low-power instrumentation and module supply needs across electronic assemblies.

Mounting Form Factor and Environmental Limits

Engineered for direct PC board mount installation, the module features a small footprint measuring 1.5 x 1.5 x 0.5 inches (38.1 x 38.1 x 12.7 mm). It operates reliably across an extended industrial temperature range from -40 deg C to +85 deg C.

Frequently Asked Questions

Q: What mounting method is required for the FS-TPSU-2430 converter?

A: The FS-TPSU-2430 is designed for direct PC board mounting on circuit assemblies.

Q: What input and output voltage levels does the FS-TPSU-2430 support?

A: The module accepts a 24 VDC input voltage and delivers a regulated output of 24-30 VDC at up to 1 A.
