GE DS200SLCCG3ADC – LAN Communications Card (Mark V Series)

Manufacturer: GE Boards and Turbine Control
Series: Mark V DS200
Part Number: DS200SLCCG3ADC
Functional Acronym: SLCC
Description: LAN Communications Card
Weight: Less than 1 pound
Number of Pins on 2PL Connector: 9

About the DS200SLCCG3ADC

The DS200SLCCG3ADC is a local area network (LAN) communication board developed by General Electric for use within the Mark V series. This card is installed inside GE drives to enable processing of LAN communication signals.

This model is not the original Mark V LAN Communications Card; that distinction belongs to the DS200SLCCG3 PCB, which lacks the three significant product revisions found in this version.

The Mark V Turbine Control System Series, to which this board belongs, is now considered a legacy product line following its manufacturing discontinuation due to obsolescence years after its original release.

Hardware Features & Specifications

• Signals on the DS200SLCCG3ADC board are processed via the onboard LAN Control Processor (LCP).

• Includes two removable EPROM memory cartridges for LCP program storage.

• Uses dual-ported RAM to interface with the drive’s drive control board.

• Supports both isolated and non-isolated circuits for communication signals.

• Equipped with an attachable alphanumeric keypad programmer to allow easy access to system settings and controls.

• Facilitates Input/Output communications over various Mark V boards and drives.

• Compatible with Power Supply Interface Boards such as IMCP, DCI, DCFB, and SDCI.

• Refer to Table 2 in the GEI-100162 manual for additional compatible boards.

Handling and Installation Notes

• Boards purchased from AX Control are shipped in static-resistant packaging; remove carefully after reviewing installation instructions.

• Only qualified personnel should handle and install this board.

• Wiring and installation instructions are provided in the product’s manual and datasheet.

• The DS200SLCCG3ADC board assembly includes four protective posts to safeguard the glass display area on the top of the unit.

• This model incorporates two functional product revisions and one artwork revision, rated A, D, and C respectively, distinguishing it from the original DS200SLCCG3 card.
