GE Fanuc DS200PTBAG1BBA Protection Termination Module

Product Availability

The DS200PTBAG1BBA - Termination Board is currently in stock and ships the same day.
Available in UNUSED and REBUILT conditions.

For best pricing and offers on the DS200PTBAG1BBA, please contact us. We will respond within 24 hours.

Specifications

• Part Number: DS200PTBAG1BBA

• Manufacturer: General Electric

• Product Type: Terminal Board

• Series: Mark V

Overview

The DS200PTBAG1BBA is a terminal board from the GE Mark V series, designed for use in Speedtronic turbine control systems. World of Controls offers replacement components for various turbine control systems developed and supplied by General Electric.

This termination board features numerous input and output connectors, and its form factor is longer than it is wide. It includes:

• Four vertical pin header connectors

• Vertical pin connectors

• A six-screw termination board

• A double termination board (green)

The screw connections are numbered from 1 to 79 for ease of identification.

Components & Features

• Equipped with metal oxide varistors, capacitors, resistors, and jumper switches.

• Each corner of the board has a factory drill hole, with two holes surrounded by a conductive material.

• The board is labeled with:

• Board ID number

• Coding to assist in wiring and locating

• Codes to facilitate connections to other system boards

• The board weighs approximately 1.0 pound before packaging.

• Protected with static-reducing packaging to prevent damage during transit.

Applications

The DS200PTBAG1BBA serves as a termination board for the Independent Protective Module Core. It commonly provides:

• Overspeed protection

• Flame detection
