GE Fanuc IS210BPPBH2BGB Printed Circuit Board In Stock

GE IS210BPPBH2B | Mark VI Speedtronic PCB

Manufacturer: General Electric
Series: Mark VI Speedtronic
Part Number: IS210BPPBH2B
Functional Acronym: BPPB
Functional Description: Printed Circuit Board
PCB Coating: Conformal Coating
Functional Revision: B

Overview

The IS210BPPBH2B is a printed circuit board (PCB) designed and manufactured by GE as part of the Mark VI Speedtronic turbine control system. Originally introduced in the 1960s, the Speedtronic platform has evolved to manage heavy-duty gas and steam turbines with integrated protection, control, and monitoring features.

The Mark VI system uses proprietary software tools such as Control System Toolbox and CIMPLICITY to interface with the hardware. Central control is executed through a dedicated Control Module, which communicates with the rest of the system via terminal boards and an Operator Interface (Windows-based PC).

Function and Application

The IS210BPPBH2B serves as a daughterboard or auxiliary PCB that mounts directly to the WETA board using four screws inserted through pre-drilled standoffs at each corner. Its compact design and specific component layout support critical signal processing and power conditioning functions within the larger turbine control system.

Key Hardware Features

• Electrical Components:

• Transistors

• Inductor

• Transformer

• Crystal/Oscillator

• Integrated Circuits

• TP (test point) locations for diagnostics

• Connectors:

• 2 female jack connectors

• 1 narrow multi-position female plug

• 1 three-position female plug

• Indicators:

• 2 side-by-side LEDs located on one edge for status or diagnostic indication

• Mechanical Design:

• Cutouts on three edges for specialized mounting or airflow

• Labeled with multiple identification codes: Type 6, E99006, FA/00

• Clearly printed GE logo for authenticity and identification

Mounting and Construction

• Board Attachment:
  The daughterboard mounts securely to the WETA main board using four screws and standoffs for stable operation during turbine activity.

• Coating:
  Conformal Coating provides protection against dust, moisture, and other environmental contaminants, enhancing the durability and longevity of the board.

Conclusion

The GE IS210BPPBH2B is a vital auxiliary PCB in the Mark VI Speedtronic system, providing essential processing and interface capabilities. Its robust design, reliable components, and easy integration make it a key contributor to turbine reliability and performance.
