GE IS200EHPAG1DAB Exciter Gate Pulse Amplifier Board

Description

The GE IS200EHPAG1DAB is an Exciter Gate Pulse Amplifier Board used in the EX2100 excitation control system. It amplifies and distributes gate firing pulses to six SCRs, ensuring accurate switching and system protection.

Specifications

• Model: IS200EHPAG1DAB

• Manufacturer: GE General Electric

• System Compatibility: GE EX2100 Excitation System

• Function: Amplifies and distributes gate pulses to six SCRs

• Power Supply Input: 125 VDC nominal

• Mounting: Interfaces between controller and power bridge

• Dimensions: 17.5 cm × 8 cm × 4.62 cm

• Weight: 0.4 kg

• Country of Origin: USA

• Condition: New or refurbished

• Warranty: 1 year

Features

• SCR Gate Pulse Amplification: Sends precise firing pulses to six Silicon Controlled Rectifiers

• Fault Monitoring: Detects and reports SCR-related faults for system safety

• Thermal Protection: Prevents overheating and ensures long-term reliability

• High Voltage Operation: Designed for robust performance in high-voltage environments

• System Integration: Connects seamlessly with ESEL board and power bridge

• Compact Design: Efficient layout for space-constrained excitation cabinets

• Industrial Grade: Built for demanding turbine and generator applications
