GE M60UA3HKHF8LH6NM8N6MU5AWXX Motor Protection Relay

Description

M60UA3HKHF8LH6NM8N6MU5AWXX is a motor protection relay from GE’s Multilin M60 series. It offers advanced protection, monitoring, and control for medium to large motors in industrial environments.

Specifications

• Model: M60UA3HKHF8LH6NM8N6MU5AWXX

• Manufacturer: GE Multilin

• Series: M60 Motor Protection Relay

• Protection Functions: Overload, thermal modeling, phase imbalance, stator differential, ground fault

• Input Support: RTD inputs and external RRTD module

• Communication Protocols: IEC 61850 Ed.1 & Ed.2, Modbus, DNP3

• Display: Full-color graphical interface

• Power Monitoring: Reverse and low forward power detection

• Rotor Monitoring: Broken rotor bar detection

• Environmental Specifications:

  • Operating Temperature: -25°C to +60°C

  • Storage Temperature: -40°C to +70°C

• Dimensions & Weight:

  • Dimensions: 35 cm × 25 cm × 13 cm

  • Weight: 4.5 kg

Features

• Advanced Thermal Modeling: Prevents overheating with voltage-dependent overload curves

• RTD Integration: Enables precise temperature monitoring for motor windings and bearings

• Stator Differential Protection: Detects internal faults for enhanced motor safety

• Flexible Startup Support: Handles reduced voltage and two-speed motor configurations

• IEC 61850 Compatibility: Seamless integration with modern substation networks

• Graphical Interface: Simplifies local diagnostics and configuration

• Real-Time Diagnostics: Improves system reliability and reduces downtime

• Scalable Deployment: Ideal for large industrial motor fleets and automation systems
