GWK 9071114 KRINTV5.1 PC Board

Description

The GWK 9071114 KRINTV5.1 PC Board delivers precise environmental control for industrial automation systems. Manufactured in Germany, it supports multiple sensor types and ensures efficient signal processing with reliable communication protocols.

Specifications

• Model: 9071114 KRINTV5.1

• Manufacturer: GWK

• Country of Origin: Germany

• Power Supply: 24V DC nominal

• Power Consumption: Less than 20W

• Signal Inputs:

  • Thermocouples: Type K, J

  • RTD Sensors: Pt100, Pt1000

  • Humidity Sensors

  • Analog Signals: 0–10V, 4–20mA

  • Digital Signals

• Setpoint Temperature Range: −50°C to 200°C

• Temperature Accuracy: ±0.3°C

• Operating Temperature: −20°C to 60°C

• Dimensions: 130 mm × 100 mm × 65 mm

• Mounting: DIN rail compatible

• Enclosure Rating: IP20 (indoor use only)

• Communication Protocols:

  • Modbus RTU

  • BACnet (optional)

Features

• Multi-Sensor Compatibility: Accepts thermocouples, RTDs, humidity, analog, and digital inputs

• Precision Control: Maintains temperature accuracy within ±0.3°C across wide operating ranges

• Efficient Signal Processing: Converts diverse input types into actionable control signals

• DIN Rail Mounting: Simplifies installation in industrial control cabinets

• Reliable Communication: Supports Modbus RTU and optional BACnet for system integration

• Compact Design: Fits easily into tight spaces with a 130×100×65 mm footprint

• Indoor Protection: IP20-rated enclosure ensures safe operation in controlled environments
