Honeywell 51309355-001 Processor Board

Specifications

  • Manufacturer: Honeywell

  • Product No.: 51309355-001

  • Condition： 10 Items in Stock

  • Product Type: Processor Board

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 100g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product details

Description

Honeywell 51309355-001 – Processor Board for DR4500 Chart Recorder

Product Overview

The Honeywell 51309355-001 is a high-performance processor board engineered for the DR4500 Circular Chart Recorder. Acting as the computational hub, it manages real-time data acquisition, chart recording, and digital display of up to four process variables.

This module accepts multiple input types, including RTDs, thermocouples, and current loops, ensuring broad compatibility with industrial sensors. By supporting 1–2 digital control loops, the board enables precise process adjustments, making it ideal for applications in blast furnaces, laboratories, chemical plants, and clean rooms.

Its compact design allows direct integration into the recorder housing, while the fiber-tip pen recording system provides reliable analog traces alongside digital readouts.

 Technical Specifications

Feature Specification
Model Number 51309355-001
Manufacturer Honeywell
Product Type Processor Board
Platform Compatibility DR4500 Circular Chart Recorder
Function Records and displays up to four process variables
Supported Inputs RTDs, thermocouples, current loops
Control Outputs Supports 1–2 digital control loops
Recording Method Circular chart with fiber-tip pens
Display Digital real-time process values
Mounting PCB assembly within recorder housing
Dimensions (H × W × D) 2 × 13.5 × 24 cm
Weight 0.22 lbs (100 g)
Power Supply Integrated via recorder backplane
Country of Origin USA
