Honeywell 8U-PAOHA1 Series 8 Analog Output Module

The Honeywell 8U-PAOHA1 serves as the primary 8U-PAOHA1 Analog Output Module utilized to execute precision 4-20 mA HART analog control signaling across Honeywell Series 8 I/O system platforms.

Hardware Specifications

4-20 mA HART Loop Protocol Pass-Through and Channel Isolation

The Honeywell 8U-PAOHA1 incorporates dedicated 4-20 mA HART loop protocol modems across each channel to enable bi-directional field device communications while executing real-time current loop outputs. The architecture incorporates channel-to-channel isolation and galvanic channel-to-system isolation, preventing field-induced voltage surges, ground potential loops, and common-mode noise from propagating to backplane processing electronics. Onboard signal conditioning circuitry maintains stable 12-bit digital-to-analog conversion performance across the entire -40 to +85 deg C thermal operational window.

Frequently Asked Questions

Q: Does the 8U-PAOHA1 module allow HART diagnostic pass-through while actively driving the 4-20 mA current loop?

A: Yes, digital HART frequency-shift keying (FSK) signals are superimposed on the standard 4-20 mA analog output without disturbing the primary analog control signal.

Q: What power source is required to drive the analog current loops on this module?

A: The module relies on a nominal 24 VDC supply to power the internal digital-to-analog converters and field output loops.

Q: How does the module handle output signal stability in high-noise electrical environments?

A: Galvanic isolation circuits decouple the backplane logic from individual field loops, isolating sensitive digital processing from high-frequency field spikes and ground loops.

Field Installation Guidelines

1. Confirm that the Series 8 I/O chassis enclosure Earth ground strap is securely bonded to the main station ground point using low-impedance copper cable (minimum 4 mm2 / 10 AWG).
2. Isolate all external 24 VDC loop supply power feeds before seating or removing the 8U-PAOHA1 module from its backplane connector slot.
3. Route 4-20 mA analog output cables in shielded, twisted-pair configurations isolated from high-voltage AC lines by a distance of at least 300 mm.
4. Ground cable shields at a single point on the cabinet Earth grounding rail to prevent ground loop circulating currents.
5. Torque field wiring terminal screws to the manufacturer-specified value (0.5 to 0.6 Nm) to maintain gas-tight low-resistance contact points.
