Honeywell FC-RO-1024 Relay Output Module

Specifications

  • Manufacturer: Honeywell

  • Product No.: FC-RO-1024

  • Condition： 10 Items in Stock

  • Product Type: Relay Output Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 300g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product details

Description

Honeywell FC-RO-1024 – Relay Output Module

Product Overview

The Honeywell FC-RO-1024 is a reliable relay output module engineered for Honeywell Safety Manager and Process Manager systems. It provides 10 potential-free relay contacts, enabling flexible switching of both resistive and inductive loads. With high endurance and stable performance, it supports non-safety-critical automation tasks across diverse industrial environments.

Built with gold flash over silver alloy contacts, the module ensures long service life and reduced contact resistance. The compact form factor allows easy installation into Honeywell control racks, while its integrated watchdog function automatically de-energizes outputs during system failures, enhancing operational safety.

Technical Specifications

Feature Specification
Model Number FC-RO-1024
Manufacturer Honeywell
Product Type Relay Output Module
Platform Compatibility Honeywell Safety Manager & Process Manager
Output Channels 10 potential-free relay contacts
Max Switching Voltage 30 V AC / 36 V DC (IEC 61010-1)
Max Switching Current 2 A per channel
Max Switched Power 100 W / 1000 VA
Max Load Capacitance 100 nF
Contact Material Gold flash over silver alloy
Electrical Life 1,000,000 ops (resistive), 100,000 (inductive)
Power Supply 5 V DC @ 25 mA, 24 V DC @ 120 mA
Inductive Load Protection External suppression diode required
Watchdog Function Outputs de-energize on system failure
Form Factor 4 TE horizontal, 3 HE vertical
Dimensions (H × W × D) 2 × 13.5 × 24 cm
Weight 0.3 kg
Certifications CE, TUV, UL508, CSA
Country of Origin USA
