Honeywell TK-CCR013 Redundant Network Interface Module

The Honeywell TK-CCR013 is a redundant network interface module designed for high-availability industrial control applications. It establishes fault-tolerant communication links within PLC architectures, supporting high-speed data exchange and robust system reliability across critical control nodes.

Communication Protocols and Redundancy Architecture

The module supports Triconex TriStation and Modbus TCP/IP communication protocols over a 100Mbps Ethernet data transfer rate. It utilizes a Triple Modular Redundancy (TMR) architecture with redundant features to prevent single-point communication failures and maintain uninterrupted data paths.

Electrical Ratings and Environmental Limits

Powered by a nominal 24 VDC operating voltage with a +/-10% tolerance, the module provides 1500 VAC isolation protection to safeguard backplane circuitry from field transients. It is rated for continuous operation in ambient temperatures ranging from -40 deg C to +70 deg C, with a total unit weight of 1.96 kg and country of origin designated as USA.

Frequently Asked Questions

Q: What communication protocols are supported by the TK-CCR013 module?

A: The module supports Triconex TriStation and Modbus TCP/IP communication protocols over a 100Mbps Ethernet link.

Q: What power supply and isolation ratings does this network interface require?

A: It operates on a 24 VDC supply with a +/-10% tolerance and features 1500 VAC isolation protection.

Q: What is the operating temperature range for this module?

A: The module is engineered for deployment in environments ranging from -40 deg C to +70 deg C.
