IC693MDL655 GE Fanuc 24 VDC Positive/Negative Logic Input

Specifications

  • Manufacturer: GE

  • Product No.: IC693MDL655

  • Condition： 10 Items in Stock

  • Product Type: Positive/Negative Logic Input

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 320g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product details

Description

Description

IC693MDL655 is a 24 VDC Positive/Negative Logic Input Module from GE Fanuc, offering 32 inputs in four groups for flexible DC input handling.

Input Configuration

  • Rated Voltage: 24 VDC (Positive/Negative Logic)

  • Input Range: 0–30 VDC

  • Inputs per Module: 32 (4 groups of 8)

  • On-State Voltage: 11.5–30 VDC

  • Off-State Voltage: 0–5 VDC

  • On-State Current: Min. 3.2 mA

  • Off-State Current: Max. 1.1 mA

Electrical Specs

  • Input Current: 7.0 mA (typ. @ 24 VDC)

  • Isolation: 1500 V (field to logic), 250 V (between groups)

  • On Response Time: Max. 2 ms

  • Off Response Time: Max. 2 ms

Power Consumption

  • Internal (5V Bus): Max. 195 mA

  • From 24V Bus: Typ. 224 mA (all 32 inputs ON)

Hot Tags :

Positive/Negative Logic Input Series 90-30
