Jetter JX3-PS1 Expansion Modules

Description

The JETTER JX3-PS1 is a dedicated power supply module designed to support up to eight JX3 expansion modules. It ensures stable voltage distribution when the bus node or controller cannot provide sufficient power.

Specifications

• Model: JX3-PS1

• Manufacturer: Jetter

• Rated Input Voltage: 24 VDC (-15% to +20%)

• Input Current: Max. 0.5 A

• Power Consumption: Max. 12 W

• Supported Modules: Powers up to 8 JX3 expansion units

• Protection Features: Integrated polarity reversal protection

• Mounting Type: DIN rail (EN 50022 – 35 × 7.5 or 35 × 15)

• Protection Class: IP20

• Operating Temperature: 0°C to +50°C

• Storage Temperature: -40°C to +70°C

• Humidity Tolerance: 10% to 95%, non-condensing

• Dimensions: 131 × 101 × 25 mm

• Weight: Approx. 350 g

Features

• Reliable Power Distribution: Supplies consistent 24VDC to multiple JX3 modules

• Compact Design: Slim profile fits easily into control cabinets

• Integrated Protection: Prevents damage from polarity reversal and overload

• LED Diagnostics: Visual indicators for power and module status

• Modular Compatibility: Seamlessly integrates with JX3 bus systems and JetControl controllers

• Industrial Durability: Operates reliably in varied temperature and humidity conditions

• Easy Installation
