MOXA EDS-308-MM-SC Industrial Ethernet Switch

Description

The MOXA EDS-308-MM-SC is an 8-port unmanaged Ethernet switch designed for industrial networking. It combines copper and fiber interfaces to ensure stable communication in harsh environments.

Specifications

• Manufacturer: MOXA

• Model Number: EDS-308-MM-SC

• Port Configuration: 6 × 10/100BaseT(X) RJ45, 2 × 100BaseFX multi-mode SC

• Standards Supported: IEEE 802.3, 802.3u, 802.3x

• MAC Table Size: 2 K entries

• Packet Buffer Size: 768 Kbits

• Processing Type: Store and forward

• Alarm Contact: 1 relay output, 1 A @ 24 VDC

• Input Voltage: 9.6 to 60 VDC

• Input Current: 0.15 A @ 24 VDC

• Mounting: DIN-rail

• Dimensions: 53.6 × 135 × 105 mm

• Weight: 0.63 kg

• Operating Temperature: 0°C to 60°C

• Storage Temperature: -40°C to 85°C

• Humidity Range: 5% to 95% (non-condensing)

Features

• Dual Fiber Ports: SC connectors support multi-mode fiber for long-distance transmission

• Industrial Reliability: Operates stably in high-temperature and high-humidity conditions

• Power Redundancy: Dual DC inputs enhance uptime and fault tolerance

• Broadcast Storm Protection: Prevents network congestion in unmanaged environments

• Relay Alarm Output: Alerts for power failure or port disconnection

• Plug-and-Play Setup: No configuration required for quick deployment

• DIN-Rail Mounting: Simplifies installation in control cabinets and panels
