MU-TAIH53 51309138-225 Honeywell High Level Analog Input Module
Specifications
Manufacturer: Honeywell
Product No.: MU-TAIH53 51309138-225
Condition: 10 Items in Stock
Product Type: Analog Input Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 450g
Shipping port: Xiamen
Warranty: 12 months
Product details
Description
The Honeywell 51309138-225, also cataloged as the MU-TAIH53 High Level Analog Input Module, operates as a dedicated hardware component for high-precision data acquisition and signal conditioning within Honeywell Experion PKS and UCN control system platforms. It conditions incoming differential signals across 16 channels, accepting standard 0-10 V and 4-20 mA ranges to route digitized instrumentation data directly to central process controllers.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MU-TAIH53 (51309138-225) |
| Brand | Honeywell |
| Origin | USA |
| Weight | 0.45 kg |
| Dimensions | Standard FTA Chassis Assembly |
| Operating Temp | -20 to 60 deg C |
| Power Consumption | 1.5 W |
| Channel Count | 16 Differential Input Channels |
| Input Signal Ranges | 0-10 V, 4-20 mA |
| Measurement Accuracy | +/- 0.1 percent of full scale |
| Isolation Rating | 1500 V between field inputs and system logic |
| System Operating Voltage | 24 VDC |
| Terminal Connection Type | Type S Screw Terminals |
4-20 mA HART Loop Protocol & Channel-to-Channel Isolation
The MU-TAIH53 (51309138-225) utilizes integrated signal conditioning circuits and 1500 V galvanic isolation to isolate differential field inputs from internal process manager logic. This physical barrier eliminates ground loops and suppresses high-frequency electromagnetic interference within panel wireways. The internal Analog-to-Digital (A/D) conversion architecture ensures stable reading accuracy of +/- 0.1 percent of full scale when acquiring field values from process transmitters utilizing 4-20 mA HART loop protocol communications.
Frequently Asked Questions
Q: Does the MU-TAIH53 module support hot-swapping under live rack power conditions?
A: Physical insertion or removal must only be performed after powering down the host cabinet segment or isolating the terminal assembly to prevent backplane voltage transients.
Q: How is dual-module redundancy configured across the Type S terminal assembly?
A: Redundancy is established by pairing two MU-TAIH53 assemblies in parallel backplane slots, enabling seamless secondary channel takeover without interrupting active loop signals.
Field Installation Guidelines
- Power down the designated chassis rack before inserting or removing the module from its slot.
- Mount the module securely within an enclosure that maintains ambient temperatures between -20 and 60 deg C.
- Use shielded twisted-pair cables for all 4-20 mA and 0-10 V field inputs to minimize electromagnetic noise pickup.
- Ground the module chassis to the cabinet earth bus at a single common point to preserve the 1500 V isolation barrier.
- Torquing all Type S screw terminals prevents loose wiring contact and intermittent analog signal drops.
