PEPPERL+FUCHS 226188 FI-PFH-TR-AI-370X-GP HART Termination Board

Description

The PEPPERL+FUCHS FI-PFH-TR-AI-370X-GP termination board (Part No. 226188) is designed for Triconex v10 AI modules. It supports 16-channel analog input cards and ensures reliable HART signal integration with robust industrial-grade connectivity.

Specifications

• Model: FI-PFH-TR-AI-370X-GP

• Manufacturer: PEPPERL+FUCHS

• Part Number: 226188

• Application: Triconex v10 AI modules (3700, 3700A, 3703E, 3721)

• Channel Count: 16-channel analog input

• Field Side Connection: Pluggable screw terminals, green

• Control Side Connection: ELCO socket, 56-pin

• HART Interface: 1 x IDC plug, 26-pin

• Supply Connection: Screw terminals, green

• Core Cross Section: 0.5 to 2.5 mm² (20 to 12 AWG)

• Rated Voltage: 20.4 to 27.6 V DC (SELV/PELV)

• Degree of Protection: IP20

• Mounting Type: DIN rail

• Weight: Approximately 415 grams

• Product Origin: USA

Features

• Triconex Compatibility: Designed for AI cards including 3700, 3700A, 3703E, and 3721

• High-Density Channels: Supports 16 analog input channels for efficient signal handling

• Reliable Termination: Pluggable screw terminals ensure secure field-side wiring

• Industrial Interface: ELCO 56-pin socket provides robust control-side connectivity

• HART Integration: IDC plug enables seamless HART communication setup

• DIN Rail Mounting: Simplifies installation in control cabinets

• Voltage Range: Operates safely within 20.4 to 27.6 V DC

• Compact Design: IP20-rated enclosure suitable for industrial environments

• Certified Quality: TAN48 approval ensures compliance with system standards
