Pepperl+Fuchs KCD2-SCD-1 SMART CURRENT DRIVER

Description

The KCD2-SCD-1 SMART current driver from Pepperl+Fuchs is a single-channel signal conditioner designed to drive SMART I/P converters, valves, and positioners with galvanic isolation and HART compatibility.

Specifications

• Manufacturer: Pepperl+Fuchs

• Model Number: KCD2-SCD-1

• Product Type: SMART Current Driver

• Signal Type: Analog Output (4–20 mA)

• Supply Voltage: 19–30 V DC via Power Rail or terminals 9+, 10-

• Power Consumption: ≤700 mW

• Power Dissipation: ≤600 mW at 20 mA and 500 Ω load

• Input Connection: Terminals 5-, 6+

• Output Load: Up to 900 Ω

• Switching Frequency: <10 Hz

• Housing Width: 12.5 mm

• Protection Grade: IP20

• Functional Safety: SIL2 certified (IEC/EN 61508)

Features

• Galvanic Isolation: Separates field and control circuits for enhanced safety and signal integrity

• SMART Device Support: Drives HART-compatible I/P converters and valve positioners

• Lead Breakage Monitoring: Detects signal interruptions for proactive fault handling

• Compact Design: Slim 12.5 mm housing saves space in control panels

• Flexible Installation: Supports Power Rail and terminal-based wiring

• Reliable Performance: Maintains stable current output across varying loads

• Industrial Compliance
