Pepperl+Fuchs KCD2-SOT-EX1.LB SWITCH AMPLIFIER

Description

The KCD2-SOT-EX1.LB switch amplifier from Pepperl+Fuchs is designed for isolating and amplifying signals from NAMUR sensors. It provides reliable relay output for safe switching in hazardous environments.

Specifications

• Manufacturer: Pepperl+Fuchs

• Model Number: KCD2-SOT-EX1.LB

• Product Type: Switch Amplifier

• Input Type: NAMUR sensor input

• Output Type: Relay contact output

• Supply Voltage: 19–30 V DC

• Power Consumption: ≤1 W

• Switching Frequency: <10 Hz

• Housing Width: 12.5 mm

• Protection Grade: IP20

• Connection Method: Power Rail or terminals

• Mounting: DIN rail compatible

• Operating Temperature: -20°C to +60°C

• Weight: Approx. 150 g

Features

• NAMUR Sensor Support: Interfaces directly with proximity sensors for signal amplification

• Relay Output: Provides safe switching for control circuits and alarms

• Compact Design: Slim 12.5 mm housing fits easily into control panels

• Galvanic Isolation: Separates input and output circuits for enhanced safety

• Low Power Consumption: Efficient operation with minimal energy draw

• DIN Rail Mounting: Simplifies installation and maintenance

• Industrial Reliability: Operates in harsh environments with stable performance
