RELIANCE ELECTIRIC PSC7000 WR-D4008 Servo Controller

Description

The RELIANCE ELECTRIC PSC7000 WR-D4008 is a high-performance servo controller module designed for industrial automation. It supports real-time communication, motion control, and system diagnostics across distributed PLC networks.

Specifications

• Model: PSC7000 WR-D4008

• Manufacturer: RELIANCE ELECTRIC

• Processor: 32-bit CPU with 100 MHz clock speed

• Memory: 256 KB RAM + 2 MB flash

• Communication Protocols: EtherCAT, PROFINET, Modbus TCP

• Digital I/O Capacity: 4096 points

• Analog I/O Capacity: 128 points

• Operating Temperature Range: –10°C to +60°C (optional –20°C to +60°C)

• Protection Rating: IP31

• Dimensions: Standard module size

• Safety Certification: SIL CL2 / PLd compliant

• Power Supply: Industrial-grade AC/DC input

• Country of Origin: USA

Features

• Real-Time Communication: Supports EtherCAT master/slave configuration with <1 ms latency

• Motion Control Integration: Manages up to 12 axes with stepper motor interface and PLC macros

• Hot-Swap Capability: Allows module replacement without power-down, reducing MTTR

• Advanced Diagnostics: Generates six types of reports for fault isolation and system health

• Secure Protocols: Supports encrypted communication to prevent RF interference and cyber threats

• Modular Expansion: Easily extends via EtherCAT bus for distributed I/O deployment

• Industrial Reliability: Metal enclosure and IP31 rating ensure durability in harsh environments

• Safety Functions: Includes STO and E-Stop features for emergency shutdown compliance

• Flexible I/O Handling: Manages large-scale digital and analog inputs for complex automation tasks

• Global Compatibility: Designed for manufacturing, energy, and transportation sectors
