SPIRE 920-0403 REV B TRIGGER SUPPLY BOARD

Description

The SPIRE 920-0403 REV B Trigger Supply Board is a robust industrial automation module built for precision control and monitoring. It integrates easily with existing systems and performs reliably in harsh environments.

Specifications

• Model: 920-0403

• Power Supply: 24V DC

• Power Consumption: 15W max

• Operating Temperature: –20°C to +70°C

• Storage Temperature: –40°C to +85°C

• Dimensions: 190 mm × 130 mm × 60 mm

• Weight: 900 g

• Digital I/O Channels: 14

• Analog Inputs: 8

• Analog Outputs: 4

• Communication Protocols: Ethernet (10/100 Mbps), Modbus TCP/IP

• Status Indicators: LED indicators for power, communication, and fault diagnostics

• Mounting: DIN rail compatible

Features

• High I/O Capacity: 14 digital and 12 analog channels for versatile automation control

• Protocol Support: Seamless integration via Modbus TCP/IP and Ethernet

• Real-Time Diagnostics: LED indicators provide instant feedback on system health

• Wide Temperature Range: Operates reliably from –20°C to +70°C

• Industrial Durability: Withstands demanding conditions with extended storage tolerance

• Compact Design: Fits efficiently into control panels with DIN rail mounting

• Efficient Power Use: Low power draw at 15W for continuous operation

• Application Versatility: Ideal for manufacturing, energy management, and process control systems
