Woodward 5466-315 Analog I/O Module

Description

The Woodward 5466-315 Analog I/O Module is a high-performance industrial control unit designed for steam turbine applications. Built in the USA, it offers reliable analog signal processing, logic control, and system protection for demanding environments.

Specifications

• Manufacturer: Woodward

• Country of Origin: United States

• Model Number: 5466-315

• Power Supply: 220 V AC

• Analog Inputs/Outputs: Configurable for voltage and current signals

• Digital I/O: Supports standard DI/DO interfaces

• Program Memory: 6 MB

• Data Memory: 3 MB

• Processing Speed: 3 Hz

• Output Frequency: 6 Hz

• Communication Interfaces: Modbus, CAN bus (expandable)

• Operating Temperature: –40 °C to +60 °C

• Dimensions: 525 mm × 254 mm × 152 mm

• Weight: 0.84 kg

• Warranty: 12 months

Features

• Steam Turbine Control: Supports real-time monitoring of speed, pressure, and operational sequences

• Overspeed Protection: Integrated encoder-based safety mechanism for emergency shutdown

• PLC Compatibility: Works with Siemens, Schneider, and other mainstream control systems

• Flexible Signal Handling: Configurable analog and digital channels for diverse industrial needs

• High Reliability: MTBF over 50,000 hours with hot-swap and redundant power support

• Industrial-Grade Design: Resistant to electromagnetic interference and harsh conditions

• Expandable Architecture: Supports additional communication modules for system integration

• User-Friendly Programming
