Woodward 5466-330 Analog I/O Module

Description

The Woodward 5466-330 is a high-density analog input/output module designed for turbine and industrial control systems. Manufactured in the USA, it integrates multiple I/O functions into a compact, rugged unit for reliable automation performance.

Specifications

• Manufacturer: Woodward

• Country of Origin: United States

• Model Number: 5466-330

• Product Type: Analog Combo Input/Output Module

• Power Supply: 10–60 V DC (typically 24 V DC)

• Analog Inputs: 8 channels (0–5 V or 4–20 mA configurable)

• Analog Outputs: 4 channels (standard 4–20 mA)

• Speed Inputs: 4 channels (magnetic pickup or proximity probe compatible)

• Actuator Outputs: 2 proportional outputs (4–20 mA or 20–160 mA selectable)

• Operating Temperature: –25 °C to +70 °C

• Isolation Rating: 3 kV DC

• Mounting Type: DIN rail or panel mount

• Dimensions: 483 mm × 310 mm × 105 mm

• Weight: 1.00 kg

• Warranty: 12 months

Features

• Integrated I/O: Combines analog inputs, outputs, speed sensing, and actuator control in one module

• Flexible Configuration: Supports multiple signal types and ranges for diverse applications

• High-Speed Inputs: Enables precise speed measurement for turbine and engine control

• Proportional Control: Provides accurate actuator output for fuel or steam regulation

• Industrial Grade: Operates reliably in wide temperature ranges and harsh environments

• Compact Design: Saves panel space with high I/O density

• Seamless Integration: Compatible with Woodward control systems and standard PLCs

• Robust Isolation: Ensures safe and stable operation in electrically noisy settings
