Woodward 9907-027 Load Sharing Module

Description

The Woodward 9907-027 Load Sharing Module is a precision control device designed for generator systems. Built in the USA, it enables dynamic load balancing across multiple gensets to improve system efficiency and stability.

Specifications

• Manufacturer: Woodward

• Country of Origin: United States

• Model Number: 9907-027

• Product Type: Load Sharing Module

• Operating Voltage: 230 V AC

• Input Power: 1 kW

• Output Frequency: 50 Hz

• Frequency Range: 50–400 Hz

• Control Modes: Isochronous and Droop

• Control Type: Forward acting

• Load Sharing Capacity: Supports up to 4 modules

• Communication Protocols: RS-485, CAN bus

• Electrical Interface: Standard industry interfaces

• Terminal Type: Screw clamp terminals

• Mounting Options: Panel or rack mount

• Operating Temperature: –10 °C to +50 °C

• Storage Temperature: –20 °C to +70 °C

• Dimensions: 27.2 cm × 21.2 cm × 5.8 cm

• Weight: 1.54 kg

• Warranty: 12 months

Features

• Multi-Genset Synchronization: Balances load across up to four generators for optimized performance

• Dual Control Modes: Supports both isochronous and droop settings for flexible operation

• Forward Acting Control: Ensures responsive load adjustments under varying conditions

• Wide Frequency Range: Operates effectively across 50–400 Hz systems

• Robust Communication: Interfaces with RS-485 and CAN bus networks for system integration

• Flexible Mounting: Suitable for both panel and rack installations

• Industrial Reliability: Engineered for continuous use in demanding environments

• Compact Design: Saves space while delivering high control precision
