Yokogawa AAI543-H50/K4A00 Analog Output Module

Estimated Lead Time: 1 – 10 Working Days
Manufacturer: Yokogawa
Product No.: AAI543-H50/K4A00
Product Type: Analog Output Module
Condition: New and Original

Product Configuration

• H: With digital communication (HART protocol)

• 5: Standard switch-over response in redundant configuration, no explosion protection

• 0: Basic type

• K4A00: With KS Cable Interface Adapter (for connecting AEA4D Terminal Board) [Model: ATK4A-00]

Technical Specifications

• Number of Output Channels: 16, isolated, standard switch-over response in redundant configuration

• Input Signal: 4–20 mA

• Withstanding Voltage: 1500 V AC (between output and system, for 1 minute)

• Allowable Load Resistance: 0 to 750 Ω

• Circuit-Open Detection: Less than 0.65 mA

• Accuracy: ±48 µA

• Data Update Period: 10 ms

• Temperature Drift: ±16 µA per 10 °C

• Maximum Current Consumption:

• 230 mA (5 V DC)

• 540 mA (24 V DC)

• External Communication: Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)

Physical Specifications

• Weight: 0.4 kg

• Shipping Weight: 1.5 kg
