Allen-Bradley 2085-IQ16 Micro800 16-Channel Input Module

Product Overview

The AB 2085-IQ16 is a high-performance Micro800 input module by Allen-Bradley, engineered for precise control and monitoring in industrial automation systems.

This compact module provides 16 digital input channels, configured as 8 normally open and 8 normally closed, ensuring reliable detection from a wide range of industrial sensors and devices. It supports 12–24 VDC operating voltage and delivers a maximum load of 500 mA per channel, handling diverse input signals effectively.

With an extended operating temperature range of -40°C to +70°C, the 2085-IQ16 performs reliably in harsh environments. Its IP20 rating protects against dust and limited water splashes, enhancing durability for long-term operations.

Equipped with Modbus RTU communication over RS-485, the module integrates seamlessly with other AB systems or third-party devices, providing efficient interoperability across industrial networks. Its 10-pin IDC connector simplifies installation and wiring in compact spaces.

The module’s lightweight design (0.5 kg) and compact dimensions (88.9 × 101.6 × 47.6 mm) allow for easy integration into existing control panels, saving space without compromising functionality.

Technical Specifications

Key Features

• 16 digital input channels with mixed NO/NC configuration for versatile use

• Compact Micro800 design for efficient panel integration

• Supports Modbus RTU over RS-485 for seamless industrial communication

• Wide operating temperature range from -40°C to +70°C

• IP20-rated housing ensures protection against dust and splashes

• Handles up to 500 mA per input channel reliably

• Lightweight at 0.5 kg, simplifying installation and maintenance

FAQ

Q1: Is the AB 2085-IQ16 brand new and original?
A1: Yes, the AB 2085-IQ16 is fully factory original and brand new.

Q2: How many digital inputs does this module support?
A2: It provides 16 digital inputs, divided into 8 normally open and 8 normally closed channels.

Q3: What is the operating voltage range?
A3: The module operates efficiently at 12–24 VDC.

Q4: Can it operate in extreme temperatures?
A4: Yes, the 2085-IQ16 functions reliably from -40°C to +70°C.

Q5: What communication protocol does it use?
A5: The module supports Modbus RTU over RS-485, allowing integration with AB or third-party systems.

Q6: What protection does it provide against dust and moisture?
A6: It has an IP20 rating, protecting against dust and limited water exposure.
