Allen-Bradley 1788-MCHKR Handheld Network MediaChecker for Industrial Cables

Product Overview

The AB 1788-MCHKR is a portable handheld Network MediaChecker designed for diagnosing wiring faults, verifying cable integrity, and measuring lengths across industrial communication media. It provides accurate and reliable diagnostics for Ethernet, ControlNet, DeviceNet, and DH+/RIO systems.

This device identifies shorts, opens, miswires, and split pairs while generating detailed wire maps for twisted-pair cables. Its high-resolution length measurements allow precise cable verification from 1 m up to 650 m depending on the protocol. Equipped with a rotary switch, the 1788-MCHKR enables intuitive mode selection for quick testing in various environments.

The MediaChecker includes a built-in cable library and supports cable-specific calibration to maintain measurement accuracy. Audible alerts indicate pass/fail results and active cable detection, improving efficiency during on-site diagnostics. Compact dimensions (18.4 × 9.8 × 4.6 cm) and lightweight design (354.4 g) ensure portability and easy handling.

Powered by 2 × 1.5 V AA alkaline batteries, it offers up to 50 hours of continuous operation, suitable for extended field use. The LCD displays test results clearly, while input connectors (RJ45, DB9, BNC) support multiple cable types for versatile industrial applications.

Technical Specifications

Key Features

• Measures cable length accurately with 0.5 m resolution for Ethernet

• Detects shorts, opens, miswires, and split pairs reliably

• Generates detailed wire maps for twisted-pair diagnostics

• Supports multiple cable types including Ethernet, DeviceNet, ControlNet

• Compact and lightweight for portable field testing

• Audible alerts for quick pass/fail indication and active cable detection

• Cable-specific calibration ensures measurement accuracy

FAQ

Q1: Is the 1788-MCHKR brand new and factory original?
A1: Yes, the AB 1788-MCHKR is 100% brand new and factory original.

Q2: Do you have this device in stock?
A2: Yes, we maintain stock, and shipping usually takes 3 days to 2 weeks depending on order size.

Q3: Which shipping methods are available?
A3: We commonly use DHL, FedEx, and other reliable international logistics providers.

Q4: What if the MediaChecker has quality issues?
A4: We support returns within 30 days for verified quality problems.

Q5: What cable types can the 1788-MCHKR test?
A5: It supports Ethernet (UTP, FTP), ControlNet, DeviceNet, and DH+/RIO cables.

Q6: How long does the device operate on batteries?
A6: The 1788-MCHKR provides up to 50 hours of continuous operation using 2 AA alkaline batteries.
