HIMA 22100 Output Module for Planar4 Safety Systems

Overview

The HIMA 22100 is a high-performance 4-fold output module engineered for demanding safety-critical applications. As part of the trusted Planar4 system family, it ensures outstanding fault tolerance, reliability, and system integrity in industrial environments.

Designed and manufactured by HIMA Paul Hildebrandt, the 22100 meets the highest international safety standards, making it ideal for systems that require continuous operational safety.

Key Features

• SIL 4 / CAT.4 certified for maximum safety integrity

• Four independent output channels ensure redundancy and reliability

• Operates at 24 VDC with a 3 W power rating

• Compact and lightweight design: 2.5 × 12.7 × 20.3 cm, 0.35 lbs

• Fully compatible with HIMA Planar4 series systems

• Built with precision for HIPPS, Emergency Stop, and Shutdown Systems

Technical Specifications

Applications

The HIMA 22100 is designed to enhance operational safety and reliability across critical control systems, including:

• High Integrity Pressure Protection Systems (HIPPS)

• Emergency Stop Systems for hazardous industrial environments

• Primary Shutdown Systems to ensure safe process termination

• PLC and Machine Control within safety automation networks

Benefits

The HIMA 22100 offers unmatched stability and performance with its SIL4-certified architecture. Its compact dimensions and modular design allow fast installation on standard DIN rails, while the four output channels provide continuous process protection under high-risk conditions.

FAQ

Q1: Is the HIMA 22100 an original and new module?
Yes, all HIMA 22100 modules are brand new and 100% original from HIMA factories.

Q2: How soon can you ship the HIMA 22100 after payment?
We ship within 3 days to 2 weeks, depending on order quantity and logistics. Common carriers include DHL, FedEx, and UPS.

Q3: What happens if the product has a quality issue?
We offer a 30-day return policy for any verified quality problem.

Q4: Which systems are compatible with HIMA 22100?
The module integrates seamlessly with HIMA Planar4 systems, widely used in process control and safety instrumented systems.

Q5: What is the operating voltage and power requirement?
It operates at 24 VDC with a 3 W power consumption.
