Allen-Bradley PTQ-PDPMV1 Master Network Interface Module

Product Overview

The AB PTQ-PDPMV1 Master Network Interface Module is designed to optimize data communication and network management in industrial control systems. Featuring support for Ethernet/IP and Profinet, it ensures seamless integration and robust performance in demanding environments.

This module supports multiple connections, providing flexible connectivity options for a wide range of industrial applications. It operates at a high data transfer rate of up to 100Mbps, delivering efficient network performance for real-time control and monitoring. With its 24V DC operating voltage, the PTQ-PDPMV1 is ideal for industrial systems requiring consistent, low-power operation.

Key Features

• Communication Protocols: Ethernet/IP and Profinet for reliable data exchange across industrial systems.

• Operating Voltage: 24V DC, ensuring compatibility with various power sources.

• Data Transfer Rate: Supports speeds of up to 100Mbps, enabling fast communication.

• Temperature Range: Withstands environments from -20°C to +60°C for reliable performance.

• Humidity Range: Designed to operate in environments with 0% to 95% non-condensing humidity.

• Power Consumption: ≤ 3W, making it energy-efficient and cost-effective.

• Number of Connections: Supports multiple connections, enabling versatile networking configurations.

Technical Specifications

Application & Functions

The AB PTQ-PDPMV1 is an ideal solution for industrial control systems, providing high-performance network communication capabilities. It is commonly used in industries such as manufacturing, process control, and automation, where reliable and fast data communication is essential.

This module allows for the integration of multiple devices, making it an efficient solution for complex networking tasks. It is designed for ease of installation and configuration, with intuitive software tools that enable technicians to set up and manage the system quickly.

FAQ

Q1: What communication protocols are supported by the AB PTQ-PDPMV1?
A1: The AB PTQ-PDPMV1 supports Ethernet/IP and Profinet protocols for efficient and flexible communication.

Q2: What is the maximum data transfer rate of the AB PTQ-PDPMV1?
A2: The module supports a data transfer rate of up to 100Mbps, ensuring fast and efficient communication.

Q3: What is the operating voltage for the AB PTQ-PDPMV1?
A3: The module operates on 24V DC, suitable for industrial power systems.

Q4: What environmental conditions can the AB PTQ-PDPMV1 withstand?
A4: It operates in a temperature range of -20°C to +60°C and a humidity range of 0% to 95% non-condensing.

Q5: How does the AB PTQ-PDPMV1 enhance network performance?
A5: The module supports multiple connections and allows for efficient data exchange, improving overall network performance in industrial systems.
